产品描述
Specification | Model | THGZQW-CCS100KW | ||
AC Nominal Input | Phases/Lines | 3 phase+ neutral + PE | ||
Voltage | 352~456V AC | |||
Frequency | 45-65Hz | |||
connecter | CCS 2+ ChAdeMo | |||
Output | Power | 100KW | ||
Voltage | 200-1000VDC | |||
Current | Single gun output maximum 200A | |||
Connection Case | Case C | |||
Cable Length | 5m | |||
Electrial Parameter | Power Factor | ≥0.99 | ||
THD Value | ≤5% | |||
Stable Voltage Accuracy | ≤±0.5% | |||
Stable Current Accuracy | ≤±1% | |||
Efficiency | ≥94% | |||
Structure Design | Housing Material | Galvanized steel body, Acrylic Panel | ||
Module Number | 5*20KW | |||
Installation Method | Vertical installation of ground | |||
LED Indicator | Green/Yellow/Red color for different states | |||
Display | One 7'' Daylight readable Color Touch Screen | |||
Emergency Stop Button | Yes | |||
Payment Method | RFID Card, Phone APP with backend, mobile APP code scanning charging, card charging etc | |||
Communication | Charger v.s. EV | PLC | ||
Charger v.s. Backend | Ethernet/GPRS/4G communication | |||
Communication Protocol | OCPP1.6 | |||
Environmental in dex | Operating Temperature | -30℃ ~ +55℃ | ||
Working Humidity | 5% ~ 95% no condensation | |||
Working Altitude | ≤2000m | |||
Protection Grade | IP54 | |||
Application Site | Indoor/Outdoor | |||
Cooling Method | The fan cooling | |||
Security Protection | Multiple Protection | Over/Under voltage protection, Overload protection, Short circuit protection, Over/Under temperature protection, Grounding protection, Surge protection, Leakage protection |
||
Warranty | 1 year | |||
Package Information | Product Dimension(W*D*H) | 550*800*1950mm | ||
Net Weight | 230kg | |||
External Packing | Wooden case | |||
